iQ Tesla Proportional Valve
Now available in Normally Open configuration!
The iQ Tesla Proportional Valve emerges as a compelling option in the competitive valve market, offering optimized travel and flow within specified orifice sizes and pressure thresholds.
Diversity and Reliability
Featuring orifice sizes of .032" and .062", they offer versatility to match diverse application needs while maintaining hysteresis below 10% for precision and accuracy. Swift time response of less than 20 ms ensures timely performance.
Adaptability and Resilience
Operating within a pressure range of 0-100 psig, the iQ Tesla adapts effortlessly to varying pressure conditions. Seal options including BUNA, FKM, and EPDM enhance resilience and suitability for different environments. Temperature flexibility from 32 to 120°F ensures consistent operation in various conditions. Constructed with 300 and 400 series stainless steel, the iQ Tesla excels in durability and compatibility with various fluids. Voltage options of 12 VDC or 24 VDC provide flexibility in power supply while the 12 inch 22 AWG lead wires simplify installation and connectivity. Weighing merely 14 oz with stainless steel, it offers a balance between lightweight design and sturdy construction.
Specifications
-
Function: 2-Way Normally Open
-
Orifice Size:
-
0.032" (0.813mm)
-
0.062" (1.575mm)
-
-
Hysteresis: <10% of full scale
-
Power Consumption: 3W - 7W
-
Response Time: < 20 ms
-
Pressure Range: 0 - 100 psig
-
Temperature Range: 32 - 120F
-
Seal Material: FKM
-
Wetted Material:
-
300 Series SS
-
400 Series SS
-
-
Porting:
-
Manifold
-
1/8" NPT
-
5/16"-24 Screw-On
-
1/4" Push-On
-
-
Media:
-
Air
-
Non-Corrosive Gases
-
Liquid
-
-
Voltage:
-
12 VDC
-
24 VDC
-
-
Lead Wires: 22 AWG, 12" Length
-
Weight: 14 oz
-
Life Cycle: 10M
This table is intended for reference only.
