iQ Mini Proportional Valve

Media Isolation in a smaller package.

The iQ Mini proportional valve offers media isolation from all moving members inside the solenoid. These isolated proportional valves are ideal for lower flow applications that require isolation due to harmful media. The Mini series also uses our innovative suspended armature deisgn for greater long term performance and hysterisis.

Mini Proportional Valve

Specifications

Function: 2 Way Normally Closed



Orifice Size: .032"-0.156"



Hysterisis: <10%



Time Response: < 20 ms



Pressure range: 0-100 psig, 0-30 inHg



Seal: Nitrile / Viton / EPDM



Temperature Range: -40 to 250 F



Wetted Material: 303 SS/Aluminum, 303 SS



Voltage: 12 VDC / 24 VDC



Lead Wires: 22 AWG, 6" Length



Weight: 14 oz (w/SS), 10 oz (w/Al)

Flow rate graph
